Sipmeas 3D Metrology Software
Software Desktop
Fast Multi Datum Output
You can do more than one measurement at the same time by setting the options in this window. For example you are measuring the distance between the two circles and at the same time you want the angle of the distance line with the x axis just set the options, you will get both result with just one click.
Data Management-Export
Options to save graphs as DXF or IGS files makes it possible to export our measurement to CAD and CAM for further editing. You can also “Click” the features in the graph to calculate the measurement between the elements. For example to measure the distance between the 2 circles in the graph just click the distance button and then click the two circles from the graph. The result is on the screen.
Program Hotkey Board
Customize the series of measurements according to your part and make an icon for it. Next time just press it and start the measurement. So with this software just measure one part for the others it will guide you how to measure.
Light Control
Software capable of handling 4 channel light controller with programming capability for each channel i.e.; intensity value for each channel source would be repeated at the time of running. This can also be used to contolthe 4 Quadrant LED light controller.
Tolerance Setting & Result Display
Support more than 10 types of Tolerance setting including group Tolerancing (Circularity, Concentricity, Perpendicularity, Parallelism etc.) and Result window will display all the results with tolerance values and will give an indication for PASS or FALL features.
Focus Indicator for accurate 3-D Measurement
This will indicate the best focus value and the corresponding Z value to make sure focus is clear before measurement. A must to do for 3-D measurement.
Programming and Navigation
Teach programs with one click and repeat those with the help of navigation tool bar shown in the above picture. This navigation toolbar guide you what features are to be measured and where is there exact location- just press the mouse clicks and complete part will be measured. So just measure one part other similar ones would be measured automatically.
Video Edge Detection Measurement Options
These tools automatically generates the region of interest around the feature to be measured which facilitates searching of points, lines, circles and arcs of the work piece in that region.
Deviation analysis of point data
This feature gives you the coordinates of the points taken on the element along with the form tolerance value of each point. This is very successful to analyze the irregularities on the feature. You can choose the type of result you want- Min, Max or avg. Also you can have a print out of this report.
